15/25kV Two-position Loadbreak Switch

Views: 0
Date: 2024-05-20 09:03:08
Category: IEEE Accessories

The two-position loadbreak switch is designed for use in transformer to close or open the power source.

The switch uses a manually charged over-toggle stored spring assembly to operate , which is independent of operation speed.

The silver plated copper blades are securely keyed between the vented rotor halves which ensure proper blade and contact alignment during switching.
